Gigabyte B550M Aorus Elite AMD 3rd Gen Micro ATX Motherboard
-13 %
Gigabyte B550M Aorus Elite AMD 3rd Gen Micro ATX Motherboard
- Stock: In Stock
- Brand: Gigabyte
- Model: B550M Aorus Elite
Chat Through
Contact for Bulk Quantity: 01771833944
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
Quick Compare
| Product Details | ||||
| Product | Gigabyte B550M Aorus Elite AMD 3rd Gen Micro ATX Motherboard | MSI PRO B650M-P AM5 AMD Motherboard | MSI B550M Pro VDH Wi-Fi AM4 AMD Micro-ATX Motherboard | MSI PRO B840M-B AMD AM5 mATX Motherboard |
| Image |  |
 |
 |
|
| Price | |
|
|
|
| Model | B550M Aorus Elite | PRO B650M-P | B550M-P-VDH | PRO B840M-B |
| Brand | Gigabyte | MSI | MSI | MSI |
| Availability | In Stock | In Stock | In Stock | In Stock |
| Rating | Based on 0 reviews. |
Based on 0 reviews. |
Based on 0 reviews. |
Based on 0 reviews. |
| Summary | Gigabyte B550M Aorus Elite is a Micro ATX motherboardThe Gigabyte B550M Aorus Elite is a Micro ATX motherboard designed for use with AMD Ryzen processors. It supports Ryzen 5000/4000G Series & Ryzen 3rd Generation Processors and is based on the AMD B550 chipset. The motherboard has a single 256 Mbit flash BIOS and uses a licensed AMI UEFI BIOS. It is compliant with PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, and ACPI 5.0.The Gigabyte B550M Aorus Elite features four DDR4 memory slots with dual-channel architecture, supporting up to 128GB of DDR4 memory with speeds of up to DDR4 4733(O.C.). The motherboard has several expansion slots, including a single PCI Express x16 slot (PCIEX16) that supports PCIe 4.0 x16 mode with 3rd Generation AMD Ryzen processors and PCIe 3.0 x16 mode with new Generation AMD Ryzen with Radeon Graphics processors. There is also one PCI Express x16 slot (PCIEX2) supporting PCIe 3.0 x2 mode, one PCI Express x16 slot (PCIEX1_2) supporting PCIe 3.0 x1 mode, and one PCI Express x1 slot (PCIEX1_1) supporting PCIe 3.0 x1 mode.The Gigabyte B550M Aorus Elite has one M.2 socket, which is integrated into the CPU and supports both SATA and PCIe 4.0 x4/x2 SSDs with 3rd Generation AMD Ryzen processors and SATA and PCIe 3.0 x4/x2 SSDs with 3rd Generation AMD Ryzen with Radeon Graphics processors. There is also one M.2 connector (M2B_SB), integrated into the chipset, supporting Socket 3, M key, type 2242/2260/2280 SSDs with SATA and PCIe 3.0 x2 SSDs.For graphics, the Gigabyte B550M Aorus Elite has integrated graphics in the 3rd Generation AMD Ryzen with Radeon Graphics processors. It features one DVI-D port supporting a maximum resolution of 1920x1200@60 Hz and one HDMI port supporting a maximum resolution of 4096x2160@60 Hz. The motherboard has four USB 3.2 Gen 1 ports on the back panel, two USB 3.2 Gen 1 ports available through the internal USB header, and six USB 2.0/1.1 ports (four ports on the back panel, two ports available through the internal USB header). It also has a Realtek GbE LAN chip (1000 Mbit/100 Mbit) for Ethernet connectivity.Other features of the Gigabyte B550M Aorus Elite include a Realtek ALC887 codec for high definition audio, multiple internal I/O ports, and support for APP Center, @BIOS, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, and more. It has a Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only). The motherboard also includes several headers for RGB LED lighting and addressable LED strips.FeaturesSupports 3rd Gen AMD Ryzen processorsDual-channel DDR4 memory architecture with up to 128GB capacityPCIe 4.0 support for faster data transfer and improved performanceAdvanced thermal design with heatsinks and multiple fan headersUSB 3.2 Gen 2 Type-A and Type-C connectors for high-speed data transferHDMI 2.1 with support for up to 4K resolution and up to 60Hz refresh rateRealtek 2.5GbE LAN for fast and reliable network connectivityAudio features include high-quality capacitors, audio noise guard, and a smart headphone ampRGB Fusion 2.0 with addressable LED and RGB LED headers for customizable lightingQ-Flash Plus allows for easy BIOS updates without a CPU or memory installed.. | MSI PRO B650M-P AM5 AMD MotherboardThe MSI PRO B650M-P AM5 AMD Motherboard is a high-quality motherboard designed for AMD Ryzen 7000 Series Desktop Processors in the AM5 socket. It features an AMD B650 chipset and has a micro ATX (mATX) form factor with dimensions of 243.84mm x 243.84mm. This compact size makes it suitable for smaller PC builds without compromising on performance.One notable feature of the MSI PRO B650M-P is its audio capabilities. It is equipped with the Realtek ALC897 Codec, which supports 7.1-channel high-definition audio. This ensures a rich and immersive audio experience for gaming, multimedia, and other applications.The back panel of the motherboard offers a variety of ports for connectivity. These include a DisplayPort and VGA for video output, USB 2.0 and USB 3.2 Gen 1 Type-A ports for peripheral devices, a 2.5G LAN port for high-speed networking, audio connectors for speakers and microphones, a Flash BIOS Button for easy firmware updates, HDMI for high-resolution display support, and a USB 3.2 Gen 2 Type-A port for high-speed data transfer.In terms of expansion slots, the MSI PRO B650M-P provides one PCI-E x16 slot for a graphics card and two PCI-E x1 slots for additional expansion cards. It also features internal connectors, including power connectors, CPU and system fan connectors, front panel connectors, USB ports, and RGB LED connectors, allowing for customization and flexibility in PC builds.The motherboard supports up to 192GB of DDR5 memory across four memory slots. It can achieve memory speeds of up to DDR5 6000+ MHz through overclocking, offering excellent performance for memory-intensive tasks and applications.For storage, the MSI PRO B650M-P includes two M.2 slots, supporting PCIe 4.0 x4 for high-speed NVMe SSDs, as well as four SATA 6G ports for traditional hard drives or SSDs. It also supports RAID configurations for both SATA and M.2 NVMe storage devices, offering data redundancy and performance optimization.The onboard graphics capabilities of the motherboard feature an HDMI port with support for 4K resolution at 60Hz, a DisplayPort with support for 4K resolution at 60Hz, and a VGA port with a maximum resolution of 1920x1200 at 60Hz. This makes it suitable for both casual and professional users who require reliable display connectivity.The MSI PRO B650M-P AM5 AMD Motherboard is compatible with Windows 11 64-bit and Windows 10 64-bit operating systems, ensuring broad software compatibility. It also supports AMD MULTI-GPU configurations, allowing users to install multiple graphics cards for enhanced gaming or professional applications.FeaturesAMD B650 Chipset: The motherboard utilizes the AMD B650 chipset, which provides reliable performance and compatibility with AMD Ryzen 7000 Series Desktop Processors in the AM5 socket.mATX Form Factor: With dimensions of 243.84mm x 243.84mm, the motherboard follows the micro ATX form factor, making it suitable for compact PC builds without sacrificing functionality.Audio Enhancement: The Realtek ALC897 Codec delivers 7.1-channel high-definition audio, ensuring exceptional sound quality for an immersive audio experience during gaming, multimedia playback, and other applications.Diverse Back Panel Ports: The back panel is equipped with various ports, including DisplayPort, VGA, keyboard/mouse, USB 2.0, 2.5G LAN, audio connectors, Flash BIOS Button, HDMI, USB 3.2 Gen 1 (Type-A), and USB 3.2 Gen 2 (Type-A). These ports enable flexible connectivity options for external devices and peripherals.Expansion Slots: The motherboard features one PCI-E x16 slot for a graphics card and two PCI-E x1 slots for additional expansion cards, providing expandability for various hardware upgrades.Internal I/O Connectors: The internal I/O connectors consist of power connectors (ATX_PWR and CPU_PWR), CPU and system fan connectors, pump fan connector, front panel connectors (JFP), chassis intrusion connector (JCI), front audio connector (JAUD), com port connector (JCOM), addressable V2 RGB LED connectors (JARGB_V2), RGB LED connectors (JRGB), TPM pin header (supporting TPM 2.0), USB 2.0 ports, USB 3.2 Gen 1 Type-A ports, and USB 3.2 Gen 2 Type-C ports. These connectors offer flexibility for internal component installations and customization.Realtek 8125BG 2.5G LAN: The motherboard incorporates the Realtek 8125BG LAN chip, providing a high-speed 2.5G LAN connection for fast and reliable networking.Memory Support: The motherboard supports up to 192GB of DDR5 memory across four memory slots. It supports memory speeds of DDR5 6000+ MHz (OC), allowing for fast and efficient data processing. The motherboard also supports dual-channel mode and non-ECC, unbuffered memory.AMD MULTI-GPU Support: The motherboard offers support for AMD MULTI-GPU configurations, enabling the installation of multiple graphics cards for enhanced gaming or professional applications.Storage Options: The motherboard provides two M.2 slots that support PCIe 4.0 x4 for high-speed NVMe SSDs, along with four SATA 6G ports for traditional hard drives or SSDs. It also supports RAID configurations for both SATA and M.2 NVMe storage devices, allowing for data redundancy and improved performance.Overall, the MSI PRO B650M-P AM5 AMD Motherboard combines reliable performance, expandability, and a range of features suitable for various computing needs. Whether you're building a gaming rig or a productivity workstation, this motherboard provides a solid foundation for a high-performing system... | MSI B550M Pro VDH Wi-Fi Motherboard SPECIFICATIONS Supported CPU Supports AM4 socket 3rd Gen AMD Ryzen processors, and future AMD Ryzen processors with BIOS update. Chipset AMD B550 Form Factor Micro-ATX Form Factor 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm) PCI 1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 2x PCIe 3.0 x1 slots M.2 Socket 2x M.2 slots (Key M) M2_1 slot (from AMD Processor) Supports PCIe 4.0/ 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices M2_2 slot (from AMD B550 chipset) Supports PCIe 3.0x4 Supports 2242/ 2260/ 2280 storage devices Memory Type Dual-channel memory architecture Slots 4x DDR4 memory slots Supported Memory Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE 1DPC 1R max speed 4400 MHZ 1DPC 2R max speed 3733 MHZ 2DPC 1R max speed 3866 MHZ 2DPC 2R max speed 3466 MHZ Supports non-ECC UDIMM memory Supports ECC UDIMM memory Supports un-buffered memory Maximum Mamory 128GB Graphics 1x VGA port, supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz 1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz Max Shared Memory 16GB HDMI 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz Display Port (s) 1x DisplayPort supports a maximum resolution of 4096x2160 @60Hz USB (s) AMD B550 Chipset 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector) 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors) AMD Processor 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel LAN Port (s) 1x Realtek 8111HN Gigabit LAN controller Supported Storage AMD B550 Chipset 4x SATA 6Gb/s ports 2x M.2 slots (Key M) M2_1 slot (from AMD Processor) Supports PCIe 4.0/ 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices M2_2 slot (from AMD B550 chipset) Supports PCIe 3.0x4 Supports 2242/ 2260/ 2280 storage devices Audio Realtek ALC892 Codec 7.1-Channel High Definition Audio Internal I/O Ports 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 4x SATA 6Gb/s connectors 2x M.2 slots (M-Key) 1x USB 3.2 Gen 1 5Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump fan connector 3x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Serial port connector 1x Chassis Intrusion connector 2x 4-pin RGB LED connectors 2x 3-pin RAINBOW LED connectors 1xTPM module connector 1x Clear CMOS jumper Manufacturing Warranty 03 Years Warranty Special Features WIRELESS LAN & BLUETOOTH: Intel Dual Band Wireless-AC 3168- Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 433 Mbps speed. Supports Dual Mode Bluetooth 2.1,2.1+EDR,3.0,4.0,BLE,4.2 DESCRIPTIONS MSI B550M Pro VDH Wi-Fi Motherboard PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity. With more cores’ processors, thermal and power design is more important to make sure the temperature keeps lower. MSI extended PWM heatsink with 7W/mK thermal pad ensures even high-end processors to run at full speed with MSI motherboards. The world’s fastest SSDs can start to lower performance when getting hot. Part of the motherboards heatsink design, M.2 SHIELD FROZR is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance. MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically. Designed to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked ‘keep-out-zone’ allows for easy and safe installation and a perfect fit. MSI PRO Series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Higher efficiency makes your work easier. Utilizing 3rd Gen Ryzen processors, MSI B550 motherboards feature the latest Lightning Gen 4 M.2 which is the fastest onboard storage solution on the market with up to 64 Gb/s transfer speed. An enhanced PCB design with 2oz thickened copper increases conductivity, improving heat dissipation and performance reliability especially during overclocking. Unleash and sustain maximum performance with an aggressive VRM design built with a total of 10 phases Digital Power with Doubler Design. Combining exclusive Core Boost technology, the PRO series motherboard is ready to sustain heavy daily work. MSI lightning Gen 4 PCI-E is the latest and the fastest PCI-E data transfer solution with 64GB/s of unidirectional transfer bandwidth that has doubled compared to its previous generation. PCIe 4.0 maintains both backward and forward compatibility with older and newer specifications. Optimized by steel armor design and server-grade PCB, you can enjoy next-gen devices without any compromise. MSI OC LAB does not merely work hard on extreme overclocking. Compared to the B450 motherboard memory A-XMP profile, MSI does have great improvement in performance and efficiency for B550 motherboards. Easy to enable A-XMP profile with auto power settings to get the best memory speed and stability. Core Boost technology combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU but also creating the perfect conditions for your CPU overclocking. .. | MSI PRO B840M-B MotherboardMSI PRO B840M-B AMD AM5 mATX Motherboard is a reliable and efficient platform designed for users who want next-generation performance in a compact form factor. Featuring the AMD B840 chipset and the AM5 socket, it supports the latest Ryzen 9000, 8000, and 7000 Series processors, delivering excellent performance for gaming, multitasking, and productivity workloads. Its micro-ATX size makes it suitable for space-efficient builds without compromising essential features.Processor & Memory SupportThis motherboard fully supports AMD’s modern AM5 CPU lineup, ensuring strong upgrade flexibility. It includes two DDR5 UDIMM slots with support for speeds ranging from JEDEC 4800 MT/s up to 8000+ MT/s (OC), depending on processor capabilities. With a maximum capacity of 128GB, dual-channel architecture, AMD EXPO, AMD POR, and full overclocking support, the PRO B840M-B is ready for high-bandwidth computing and demanding applications.Storage & ExpansionThe board is equipped with 2× PCIe 4.0 M.2 slots, both sourced directly from the CPU and supporting 2280/2260 NVMe SSDs for rapid boot times and fast file transfers. The second M.2 slot adjusts its bandwidth based on processor series, ensuring compatibility across different Ryzen models. Additionally, 4× SATA 6Gb/s ports provide support for traditional storage drives, along with RAID 0, 1, and 10 (SATA) and RAID 0 and 1 (NVMe) configurations.For expansion, the board includes 1× PCIe 4.0 x16 slot, offering full x16 bandwidth for Ryzen 9000/7000 CPUs, and 1× PCIe 3.0 x1 slot for additional cards.Graphics & ConnectivityThe MSI PRO B840M-B provides display output options through HDMI 2.1, supporting 4K 60Hz, and VGA, supporting up to 2048×1536. Connectivity is strong, with 4× USB 5Gbps rear ports, 2× USB 2.0, along with multiple front USB options including USB 5Gbps Type-C. Networking is handled by a fast and reliable Realtek 8125D 2.5G LAN interface.Internal Headers & FeaturesThe motherboard includes all standard front-panel connections, CPU and system fan headers, RGB connectors such as 3× ARGB V2, 1× RGB header, COM port, and TPM 2.0 header. MSI’s EZ Debug LEDs and EZ Memory Detection LED provide helpful troubleshooting indicators during system setup... |
